Products Description:
Model D horizontal multi-stage centrifugal pump parameters:
Type: horizontal multistage
Material: foundry iron
Capacity: 12-335 m3 / h
Head: 20-430 meters
Power: 2.2 KW to 440 KW
Working voltage: 380V or 220V and others,like 100V to 240V
Liquid Temperature: -15 ℃ to +80 ℃
The motor speed: 2900 r/min
Application:
1. water supply for high building
2. water boosting system, daily water transport
3. industrial applications
4. cooling system ,industry and agriculture water supply,clean water booster
5. Office buildings, water for construction
6. pure water reating sysems,pharmaceutical and fodd water supply
7. pressurized water supply for the technological process
D horizontal multi-stage centrifugal pump picture:
Product Performance Date:
| D horizontal multi-stage centrifugal pump | ||||
| Model | Capacity(m³ /h) | Head(m) | Head(KW) | Speed(r/min) |
| 50D8X3 |
12.6 18.0 21.6 |
29.1 25.5 21.9 |
2.2 | 2950 |
| 50D8X4 |
12.6 18.0 21.6 |
38.8 34.0 29.2 |
3 | 2950 |
| 50D8X5 |
12.6 18.0 21.6 |
48.5 42.5 36.5 |
4 | 2950 |
| 50D8X6 |
12.6 18.0 21.6 |
58.2 51.0 43.8 |
5.5 | 2950 |
| 50D8X7 |
12.6 18.0 21.6 |
67.9 59.5 51.1 |
5.5 | 2950 |
| 50D8X8 |
12.6 18.0 21.6 |
77.6 68.0 58.4 |
7.5 | 2950 |
| 50D8X9 |
12.6 18.0 21.6 |
87.6 76.5 65.7 |
7.5 | 2950 |
| D horizontal multi-stage centrifugal pump | ||||
| Model | Capacity(m³ /h) | Head(m) | Head(KW) | Speed(r/min) |
|
80D12X2 |
25.4 32.4 39.9 |
26.8 23.6 18.9 |
4 | 2950 |
| 80D12X3 |
25.4 32.4 39.9 |
40.3 35.3 28.3 |
5.5 | 2950 |
| 80D12X4 |
25.4 32.4 39.9 |
53.7 47.1 37.3 |
7.5 | 2950 |
| 80D12X5 |
25.4 32.4 39.9 |
67.1 58.9 47.1 |
11 | 2950 |
| 80D12X6 |
25.4 32.4 39.9 |
80.6 70.7 56.6 |
11 | 2950 |
| 80D12X7 |
25.4 32.4 39.9 |
94 82.5 66 |
15 | 2950 |
| 80D12X8 |
25.4 32.4 39.9 |
107.4 94 75.7 |
15 | 2950 |
| 80D12X9 |
25.4 32.4 39.9 |
120.6 106.1 84.9 |
18.5 | 2950 |
| D horizontal multi-stage centrifugal pump | ||||
| Model | Capacity(m³ /h) | Head(m) | Head(KW) | Speed(r/min) |
| 100D16X3 |
39.6 54.0 72.0 |
53.4 46.5 32.4 |
11 | 2950 |
| 100D16X4 |
39.6 54.0 72.0 |
71.2 62 43.2 |
15 | 2950 |
| 100D16X5 |
39.6 54.0 72.0 |
89 77.5 54 |
18.5 | 2950 |
| 100D16X6 |
39.6 54.0 72.0 |
106.8 93 64.8 |
22 | 2950 |
| 100D16X7 |
39.6 54.0 72.0 |
124.6 108.5 75.6 |
30 | 2950 |
| 100D16X8 |
39.6 54.0 72.0 |
142.4 124 86.4 |
30 | 2950 |
| 100D16X9 |
39.6 54.0 72.0 |
160.2 139.5 97.2 |
30 | 2950 |
| D horizontal multi-stage centrifugal pump | ||||
| Model | Capacity(m³ /h) | Head(m) | Head(KW) | Speed(r/min) |
| 125D25X2 |
72.0 101 119 |
51.2 43.0 35.0 |
22 | 2950 |
| 125D25X3 |
72.0 101 119 |
76.8 64.5 52.5 |
30 | 2950 |
| 125D25X4 |
72.0 101 119 |
102.4 86.0 70.0 |
37 | 2950 |
| 125D25X5 |
72.0 101 119 |
128 107.5 87.5 |
45 | 2950 |
| 125D25X6 |
72.0 101 119 |
153.6 129.0 105.0 |
55 | 2950 |
| 125D25X7 |
72.0 101 119 |
179.2 150.5 122.5 |
75 | 2950 |
| 125D25X8 |
72.0 101 119 |
204.8 172.0 140.0 |
75 | 2950 |
| 125D25X9 |
72.0 101 119 |
230.4 193.5 157.5 |
90 | 2950 |
| D horizontal multi-stage centrifugal pump | ||||
| Model | Capacity(m³ /h) | Head(m) | Head(KW) | Speed(r/min) |
| 150D30X2 |
119 155 190 |
66 60 52 |
45 | 1480 |
| 150D30X3 |
119 155 190 |
98.1 92.1 84.0 |
75 | 1480 |
| 150D30X4 |
119 155 190 |
130.8 122.8 112.0 |
90 | 1480 |
| 150D30X5 |
119 155 190 |
163.5 152.5 140.0 |
115 | 1480 |
| 150D30X6 |
119 155 190 |
196.2 184.2 168.0 |
135 | 1480 |
| 150D30X7 |
119 155 190 |
228.9 214.9 196.0 |
155 | 1480 |
| 150D30X8 |
119 155 190 |
261.6 245.6 224.0 |
180 | 1480 |
| 150D30X9 |
119 155 190 |
294.3 276.3 252.0 |
225 | 1480 |
| 150D30X10 |
119 155 190 |
327.0 307.0 280.0 |
225 | 1480 |
| D horizontal multi-stage centrifugal pump | ||||
| Model | Capacity(m³ /h) | Head(m) | Head(KW) | Speed(r/min) |
| 200D43X2 |
185 280 335 |
94 86 76 |
115 | 1480 |
| 200D43X3 |
185 280 335 |
141 129 114 |
155 | 1480 |
| 200D43X4 |
185 280 335 |
188 172 152 |
225 | 1480 |
| 200D43X5 |
185 280 335 |
235 215 190 |
260 | 1480 |
| 200D43X6 |
185 280 335 |
282 258 228 |
300 | 1480 |
| 200D43X7 |
185 280 335 |
329 306 266 |
350 | 1480 |
| 200D43X8 |
185 280 335 |
376 344 304 |
410 | 1480 |
| 200D43X9 |
185 280 335 |
423 387 342 |
440 | 1480 |
Any question , welcome to contact us , if you have confusion at choosing pump, we could help you choose pump as your head and capacity.
